Forged Steel Y

• Overview
• Product Description
• Product Parameters
• Detailed Photos

Overview

Basic Info.

Model NO.	G41H
Style	Vertical
Performance	Efficient Filtration
Certification	CE, ISO
Size	1/2"-2"
Operation	Hand Wheel
MOQ	1
Customized	OEM
Transport Package	Wooden Case
Trademark	SWF VALVE
Origin	China
HS Code	8481804090

Product Description

Introduction:

The Y-type filter is a common pipeline filtration device widely used in various fluid conveying systems. It is mainly used to remove impurities from the fluid and protect downstream equipment from wear and blockage. It has a Y-shaped structure, simple design, low resistance, and convenient maintenance. *Please offer the mesh of strainer *lf you want to equip with discharge blockage, you contract with our sale department
Parameter

Product Description
Structual Features:
Bolted Bonnet or Welding Bonnet


Application Standards
Design and Manufacture Conform to BS5352 MSS SP-118; Connection Ends: Socket Welded Dimension: Conform to ANSI B16.11, JB/T 1751. Screwed Ends Dimension: Conform to ANSI B1.20.1, JB/T 7306. Butt-Welded Dimension: Conform to ANSI B16.25, JB/T 12224. Flanged Ends Dimension: Conform to ANSI B16.5, JB/T 793. Test and Inspection Conform to API 598, GB/T 13927, JB/T 9092. Materials Conform to ANSI/ASTM specifications. Main Materials A105, LF2, F5, F11, F22, 304(L), 316(L), F347, F321, F91, Monel, Alloy 20, etc.


Structural Drawing: Product Parameters

Size	DN15 - DN80 (1/2" - 2")
Pressure	Class 800 - Class 2500
Temperature	-29ºCto+425ºC
Material	A105, LF2, F5, F11, F22, 304(L), 316(L), F347, F321, F91, Monel, Alloy 20, etc.
Media	Water, Oil, Gas, Steam, Corrosive Media, etc.

Detailed Photos
